EVA Rubber Kneader Machine 75 Liter 110000W Rubber Mixing Banbury Machine

Product Categories
Qingdao Honghesheng Industry Co., Ltd.
Contact Now

EVA Rubber Kneader Machine 75 Liter 110000W Rubber Mixing Banbury Machine

  • 1
  • 2
  • 3

Brand Name : HHS

Model Number : XSN-55

Certification : CE

Place of Origin : Shandong, China

MOQ : 1 set

Price : USD10000-15000/SET

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 300 sets/month

Delivery Time : 30 working days

Packaging Details : wood package and 20/40 GP/HC

Condition : New

Batch Time(times/hour) : 10 times/hour

Total Capacity(L) : 55L

Marketing Type : New Product 2021

Warranty : 3 Year

Core Components : PLC, Engine, Bearing, Gearbox, Motor, Pressure vessel, Gear, Pum

Voltage : 380V,Customer's Request,380V/50HZ

Power(w) : 75KW

Type : Rubber Kneader,Electric heating water cooling

Color : orange,Blue or Green,customized

Application : Rubber / Plastic Mixing,Mixing Rubber or Press rubber sheet

After-sales service provided : Engineers available to service machinery overseas

Weight : 7800KG

Dimension(l*w*h) : 3200*1900*2880mm

Contact Now

EVA Rubber Kneader Machine 75L Rubber Mixing Banbury Machine

1. Product Description

This machine is to mix and plasticize the plastics ( such as TPR, EVA, color master batch, rubber etc..) in the airtight, pressure, heating conditions (temperature and pressure are all controllable).It is a small machine with the virtues of small volume, low consumption, high precision controlling of temperature, pressure controllable and easy handling of loading and discharging materials, etc., which is suitable for sampling and improving formulas in plastics. It is also feasible for small production, which can avoid wasting resources by using big power machineries for sampling or for small production. The machine is suitable for testing and production in all professional granule factories.


2. Machine Parameters:

Model

X(S)N-55

X(S)N-75X30

Total volume of

mixing chamber

125L 180L

Working volume

of mixing chamber

55L 75L

Driving motor

power

 75KW 110KW

Tilting motor

power

 2.2KW 4KW
Tilting angle 140° 140°

Rotational speed

of the rotor

(front/rear)

30/24.5

r/min

30/24.5

r/min

Pressure of

compressed air

 0.6-0.8MPa 0.6-08MPa

Capacity of

compressed air

 ≥1.0m³/min ≥1.0m³/min

Pressure of

cooling water

 0.3-0.4MPa 0.3-0.4MPa

Pressure of

heating steam

(plastic mixing)

 0.5-0.8Mpa 0.5-0.8Mpa

Overall

dimension

3280X1930

X3070mm

3330X2620

X3340mm
Weight 7800Kg 10500Kg

3. Product Show

EVA Rubber Kneader Machine 75 Liter 110000W Rubber Mixing Banbury MachineEVA Rubber Kneader Machine 75 Liter 110000W Rubber Mixing Banbury MachineEVA Rubber Kneader Machine 75 Liter 110000W Rubber Mixing Banbury MachineEVA Rubber Kneader Machine 75 Liter 110000W Rubber Mixing Banbury MachineEVA Rubber Kneader Machine 75 Liter 110000W Rubber Mixing Banbury MachineEVA Rubber Kneader Machine 75 Liter 110000W Rubber Mixing Banbury Machine

EVA Rubber Kneader Machine 75 Liter 110000W Rubber Mixing Banbury Machine

EVA Rubber Kneader Machine 75 Liter 110000W Rubber Mixing Banbury MachineEVA Rubber Kneader Machine 75 Liter 110000W Rubber Mixing Banbury MachineEVA Rubber Kneader Machine 75 Liter 110000W Rubber Mixing Banbury MachineEVA Rubber Kneader Machine 75 Liter 110000W Rubber Mixing Banbury MachineEVA Rubber Kneader Machine 75 Liter 110000W Rubber Mixing Banbury Machine
